| Image | Buy Product | Part Number | Datasheet | Rated V | Nom. Cap. (F) | ESR DC (mΩ) | ESR AC (mΩ) | Leakage Current (µA) |
Dimensions (mm) | Rated | Weight/Unit (g) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (1 KHz) | (72 hrs @ 25C) | L | W | H | d | LS | Current (A) | ||||||||
 |
Buy Product | PBL-0.25/5.4 | Datasheet | 5.4 | 0.25 | 3600 | 1400 | 80 | 17 | 0.6 | 12 | 18 | 10 | 0.36 | 0.06 |
|
|
Buy Product | PBL-0.47/5.4 | Datasheet | 5.4 | 0.47 | 1400 | 630 | 80 | 17 | 0.6 | 12 | 18 | 10 | 0.79 | 0.06 |
|
|
Buy Product | PBL-0.5/5.4 | Datasheet | 5.4 | 0.5 | 1500 | 760 | 80 | 20 | 0.6 | 9.3 | 14 | 8 | 0.79 | 0.06 |
|
|
Buy Product | PBL-0.75/5.4 | Datasheet | 5.4 | 0.75 | 820 | 380 | 80 | 19 | 0.6 | 12 | 18 | 10 | 1.25 | 0.06 |
|
|
Buy Product | PBL-1.0/5.4 | Datasheet | 5.4 | 1 | 700 | 360 | 90 | 21 | 0.6 | 12 | 18 | 10 | 1.59 | 0.06 |
|
|
Buy Product | PBL-1.65/5.4 | Datasheet | 5.4 | 1.65 | 580 | 300 | 180 | 25 | 0.6 | 12 | 22 | 12 | 2.28 | 0.06 |
|
|
Buy Product | PBL-11.0/5.4 | Datasheet | 5.4 | 11 | 90 | 60 | 580 | 40 | 0.8 | 18.2 | 27 | 14 | 14.92 | 0.06 |
|
|
Buy Product | PBL-15.0/5.4 | Datasheet | 5.4 | 15 | 70 | 50 | 620 | 37 | 0.8 | 24.1 | 34 | 18 | 19.76 | 0.06 |
|
|
Buy Product | PBL-2.0/5.4 | Datasheet | 5.4 | 2 | 500 | 300 | 190 | 25 | 0.6 | 15.4 | 22 | 12 | 2.7 | 0.06 |
|
|
Buy Product | PBL-2.5/5.4 | Datasheet | 5.4 | 2.5 | 320 | 180 | 190 | 25 | 0.6 | 15.4 | 22 | 12 | 3.75 | 0.06 |
|
|
Buy Product | PBL-3.0/5.4 | Datasheet | 5.4 | 3 | 260 | 140 | 190 | 25 | 0.6 | 15.4 | 22 | 12 | 4.55 | 0.06 |
|
|
Buy Product | PBL-4.0/5.4 | Datasheet | 5.4 | 4 | 200 | 120 | 190 | 30 | 0.6 | 15.4 | 22 | 12 | 6 | 0.06 |
|
|
Buy Product | PBL-5.0/5.4 | Datasheet | 5.4 | 5 | 170 | 120 | 200 | 35 | 0.6 | 15.4 | 22 | 12 | 7.3 | 0.06 |
